Change App Theme

This guide explains how to customize the color scheme of the ELMS (E-Learning Management System) Flutter application for both light and dark themes.

Overview​

The ELMS app uses a centralized color management system that supports both light and dark themes. All theme colors are defined in a single file, making it easy to customize the entire app's appearance.

File Location​

Main Color Configuration File:

lib/core/constants/app_colors.dart

Color Structure​

The app defines colors in three categories:

1. Light Mode Colors​

These colors are used when the app is in light theme mode:

Color NameDefault ValuePurpose
primaryColor#5A5BB5 (Purple)Main theme color used for primary actions, buttons, and branding
secondaryColor#FFFFFF (White)Card backgrounds and form field backgrounds
backgroundColor#F2F5F7 (Light Gray)Screen background color
borderColor#D8E0E6 (Gray)Border color for inputs, cards, and dividers
errorColor#DB3D26 (Red)Error messages and validation states

2. Dark Mode Colors​

These colors are used when the app is in dark theme mode:

Color NameDefault ValuePurpose
darkPrimaryColor#7273D3 (Light Purple)Main theme color for dark mode
darkSecondaryColor#787878 (Gray)Card and field backgrounds in dark mode
darkBackgroundColor#101010 (Almost Black)Screen background in dark mode
darkBorderColor#343536 (Dark Gray)Borders in dark mode
darkErrorColor#DB3D26 (Red)Error messages in dark mode

3. Custom Constant Colors​

These colors remain the same in both light and dark modes:

Color NameDefault ValuePurpose
infoColor#0186D8 (Blue)Information messages and notifications
warningColor#E29512 (Orange)Warning messages
successColor#34A853 (Green)Success messages
darkColor#000000 (Black)Text and icons (adapts in dark mode)

How to Change Colors​

Step 1: Open the Color Configuration File​

Navigate to and open:

lib/core/constants/app_colors.dart

Step 2: Modify the Desired Colors​

The file contains static color constants. To change a color, simply update its hex value:

// Example: Changing primary color from purple to blue
static const Color primaryColor = Color(0xff5A5BB5);  // Old purple
static const Color primaryColor = Color(0xff2196F3);  // New blue

Step 3: Color Format​

Colors are defined using hexadecimal values with the Color() constructor:

Format Options:

  1. Hex with alpha (most common):

    Color(0xffRRGGBB)
    // ff = alpha (opacity), RR = red, GG = green, BB = blue

  2. ARGB format:

    Color.fromARGB(255, red, green, blue)
    // 255 = fully opaque, then RGB values from 0-255

  3. RGBA format:

    Color.fromRGBO(red, green, blue, opacity)
    // RGB values from 0-255, opacity from 0.0 to 1.0

Example: Complete Theme Color Change​

Let's say you want to change the app to use a green theme:

Light Mode Changes​

// Primary color to green
static const Color primaryColor = Color(0xff4CAF50);

// Keep secondary (white) as is
static const Color secondaryColor = Color(0xffffffff);

// Light green background
static const Color backgroundColor = Color(0xffE8F5E9);

// Green-tinted border
static const Color borderColor = Color(0xffC8E6C9);

// Keep error red
static const Color errorColor = Color(0xffDB3D26);

Dark Mode Changes​

// Dark mode primary - lighter green
static const Color darkPrimaryColor = Color(0xff81C784);

// Keep dark secondary as is
static const Color darkSecondaryColor = Color.fromRGBO(120, 120, 120, 1);

// Dark green background
static const Color darkBackgroundColor = Color(0xff1B5E20);

// Dark green border
static const Color darkBorderColor = Color(0xff2E7D32);

// Keep error red
static const Color darkErrorColor = Color(0xffDB3D26);

Theme Mapping​

The colors from AppColors are mapped to Flutter's ColorScheme in lib/core/theme/app_theme.dart:

Light Theme Mapping​

  • primary → primaryColor
  • surface → secondaryColor (cards, sheets)
  • outline → borderColor
  • error → errorColor
  • scaffoldBackgroundColor → backgroundColor

Dark Theme Mapping​

  • primary → darkPrimaryColor
  • surface → darkBackgroundColor (slightly brightened)
  • outline → darkBorderColor
  • error → darkErrorColor
  • scaffoldBackgroundColor → darkBackgroundColor

Testing Your Changes​

After changing colors:

  1. Hot Reload: Press r in your terminal or use your IDE's hot reload feature
  2. Test Both Themes:
    • Switch between light and dark mode in the app
    • Verify all screens look correct
  3. Check Contrast: Ensure text is readable on all backgrounds
  4. Test Components:
    • Buttons
    • Text fields
    • Cards
    • Dialogs
    • Navigation bars

Best Practices​

  1. Maintain Contrast: Ensure sufficient contrast between text and backgrounds for accessibility
  2. Consistent Dark Mode: Dark mode colors should be lighter versions of light mode colors
  3. Brand Consistency: Use colors that align with your brand identity
  4. Test Thoroughly: Always test both light and dark themes after changes
  5. Use Color Tools: Use tools like Coolors.co or Adobe Color to generate harmonious color palettes

Color Accessibility​

Follow WCAG 2.1 guidelines for color contrast:

  • Normal text: Minimum contrast ratio of 4.5:1
  • Large text: Minimum contrast ratio of 3:1
  • UI components: Minimum contrast ratio of 3:1

Test your colors using tools like WebAIM Contrast Checker.

Getting Color Codes​

From Design Tools​

  • Figma: Select color → Copy as CSS → Extract hex
  • Adobe XD: Use color picker → Copy hex value
  • Sketch: Color picker → Hex value

From Images​

  • Use online color pickers like ImageColorPicker.com
  • Upload your logo/brand image to extract exact colors

Converting Colors to Flutter Format​

If you have a hex color like #5A5BB5:

// Add 'ff' prefix for full opacity and '0x' for Flutter
Color(0xff5A5BB5)

Troubleshooting​

Q: My changes aren't showing up

  • Try hot restart instead of hot reload (press R in terminal)
  • Rebuild the entire app

Q: Colors look different in dark mode

  • Make sure you updated both light AND dark color variants
  • Check app_theme.dart for any color transformations

Q: Text is not readable

  • Increase contrast between text and background colors
  • Check if you need to adjust text colors separately

Q: Some parts of the app didn't change color

  • Some widgets might use hardcoded colors (not recommended)
  • Search for Color(0x in the codebase to find hardcoded colors
